High Pressure Resistance

Adoption of an RBP 22 atm* low compliance balloon provides superior lesion dilation.
*RBP: Balloon diameter 4 mm • 5 mm/22 atm, 6 mm/20 atm, 7 mm/18 atm

High Crossability

Improved tip flexibility and optimized shaft ensures excellent crossability.

Optimized for VAIVT

New concept PTA balloon, optimized for VAIVT, offers excellent dilation and tracking performance.

Catalogue number	Balloon diameter (mm)	Balloon length (mm)	Effective length of catheter (cm)	Shaft diameter (Fr)	Guidewire maximum diameter (inch)	Compatible sheath (Fr)
SH45-4020	4.0	20	45	3.8/1.25	0.018	4
SH45-5020	5.0	20	45	3.8/1.25	0.018	4
SH45-6020	6.0	20	45	3.8/1.25	0.018	5
SH45-7020	7.0	20	45	3.8/1.25	0.018	5
SH45-4040	4.0	40	45	3.8/1.25	0.018	4
SH45-5040	5.0	40	45	3.8/1.25	0.018	4
SH45-6040	6.0	40	45	3.8/1.25	0.018	5
SH45-7040	7.0	40	45	3.8/1.25	0.018	5
SH75-4020	4.0	20	75	3.8/1.25	0.018	4
SH75-5020	5.0	20	75	3.8/1.25	0.018	4
SH75-6020	6.0	20	75	3.8/1.25	0.018	5
SH75-7020	7.0	20	75	3.8/1.25	0.018	5
SH75-4040	4.0	40	75	3.8/1.25	0.018	4
SH75-5040	5.0	40	75	3.8/1.25	0.018	4
SH75-6040	6.0	40	75	3.8/1.25	0.018	5
SH75-7040	7.0	40	75	3.8/1.25	0.018	5
