Product Information

SHIDEN HP

Product Name

SHIDEN HP
SHIDEN HP
SHIDEN HP
SHIDEN HP

Ordering Information

ShaftOuterDiameter(Fr/mm)
Catalogue Number GTIN Ballon Diameter (mm) Ballon Length (mm) Distal Proximal Compatible Sheath (Fr)
SD3-20020 04540778171015 2.0 20 3.9/1.30 3.5/1.15 4
SD3-25020 04540778171022 2.5 4
SD3-30020 04540778171039 3.0 4
SD3-40020 04540778171046 4.0

3.9/1.30

3.9/1.30

5
SD3-50020 04540778171053 5.0 5
SD3-60020 04540778171060 6.0 5
SD3-20040 04540778171077 2.0 40

3.9/1.30

3.5/1.15

4
SD3-25040 04540778171084 2.5 4
SD3-30040 04540778171091 3.0 4
SD3-40040 04540778171107 4.0 3.9/1.30 3.9/1.30 5
SD3-50040 04540778171114 5.0 5
SD3-60040 04540778171121 6.0 5
SD3-20100 04540778172463 2.0 100

3.9/1.30

3.5/1.15

4
SD3-25100 04540778172470 2.5 4
SD3-30100 04540778172487 3.0 4
SD3-40100 04540778172494 4.0 3.9/1.30 3.9/1.30 5
SD3-50100 04540778172500 5.0 6
SD3-60100 04540778172517 6.0 6
SD3-40150 04540778172555 4.0 150

3.9/1.30

3.9/1.30

5
SD3-50150 04540778172562 5.0 6
SD3-60150 04540778172579 6.0 6
SD3-20200 04540778172524 2.0 200

3.9/1.30

3.5/1.15

4
SD3-25200 04540778172531 2.5 4
SD3-30200 04540778172548 3.0 4
Catheter Effective Length : 1,600mm
Maximum Guidewire Outer Diameter : 0,014inch
