OHICHO II

*This is English translation of web-site intended for viewers in Japan. Therefore, products shown may not be qualified for supply outside of Japan. Please send us message if you have any inquiries pertaining to products approval or supply outside of Japan.

Rated Burst Pressure of 22 atm*

Suitable for dilatation of highly calcified lesions.
*RBP; Balloon Diameter 4mm•5mm/22atm, 6mm/20atm, 7mm/18atm

Low-Compliant Balloon

New balloon molding method reduces the occurrence of dog-bone phenomenon.

Compatible with 5Fr Sheath owing to reduced balloon wall thickness

Insertion and reinsertion performance into the sheath is improved (compatible with balloons up to 6 mm in diameter).

Catalogue number	Effective length of catheter (cm)	Balloon diameter (mm)	Balloon length (mm)	Shaft diameter (Fr/mm)	Guidewire maximum diameter (inch)	Compatible sheath (Fr）
L2-454020	45	4.0	20	5.0/1.65	0.035	5
L2-455020	45	5.0	20	5.0/1.65	0.035	5
L2-456020	45	6.0	20	5.0/1.65	0.035	5
L2-457020	45	7.0	20	5.0/1.65	0.035	6
L2-454040	45	4.0	40	5.0/1.65	0.035	5
L2-455040	45	5.0	40	5.0/1.65	0.035	5
L2-456040	45	6.0	40	5.0/1.65	0.035	5
L2-457040	45	7.0	40	5.0/1.65	0.035	6
L2-754020	75	4.0	20	5.0/1.65	0.035	5
L2-755020	75	5.0	20	5.0/1.65	0.035	5
L2-756020	75	6.0	20	5.0/1.65	0.035	5
L2-757020	75	7.0	20	5.0/1.65	0.035	6
L2-754040	75	4.0	40	5.0/1.65	0.035	5
L2-755040	75	5.0	40	5.0/1.65	0.035	5
L2-756040	75	6.0	40	5.0/1.65	0.035	5
L2-757040	75	7.0	40	5.0/1.65	0.035	6
