18YOROI HC
18YOROI HC
Hydrophilic Coating
Hydrophilic Coating（HC） of the balloon improves the crossability to the lesion compared to our previous product
Non-compliant Balloon
The balloon has a wide working range and can be firmly expanded at low pressure or high pressure
Shaft Outer Diameter：3.9Fr(1.30mm)
Maximum Guidewire Outer Diameter：0.018inch
Maximum Guidewire Outer Diameter：0.018inch
| Catalogue Number | Catheter Effective Length (mm) |
Balloon Diameter (mm) |
Balloon Length (mm) |
Shaft Diameter (Fr/mm) |
Compatible Sheath (Fr) |
|---|---|---|---|---|---|
| YR45-4020SC | 450 | 4.0 | 20 | 3.9/1.30 | 4 |
| YR45-5020SC | 5.0 | 20 | 5 | ||
| YR45-6020SC | 6.0 | 20 | 5 | ||
| YR45-4040SC | 4.0 | 40 | 4 | ||
| YR45-5040SC | 5.0 | 40 | 5 | ||
| YR45-6040SC | 6.0 | 40 | 5 | ||
| YR45-7040SC | 7.0 | 40 | 6 | ||
| YR45-4060SC | 4.0 | 60 | 5 | ||
| YR45-5060SC | 5.0 | 60 | 5 | ||
| YR45-6060SC | 6.0 | 60 | 6 | ||
| YR45-7060SC | 7.0 | 60 | 6 | ||
| YR45-4080SC | 4.0 | 80 | 5 | ||
| YR45-5080SC | 5.0 | 80 | 5 | ||
| YR45-6080SC | 6.0 | 80 | 6 | ||
| YR75-4020SC | 750 | 4.0 | 20 | 4 | |
| YR75-5020SC | 5.0 | 20 | 5 | ||
| YR75-6020SC | 6.0 | 20 | 5 | ||
| YR75-4040SC | 4.0 | 40 | 4 | ||
| YR75-5040SC | 5.0 | 40 | 5 | ||
| YR75-6040SC | 6.0 | 40 | 5 | ||
| YR75-7040SC | 7.0 | 40 | 6 | ||
| YR75-4060SC | 4.0 | 60 | 5 | ||
| YR75-5060SC | 5.0 | 60 | 5 | ||
| YR75-6060SC | 6.0 | 60 | 6 | ||
| YR75-7060SC | 7.0 | 60 | 6 | ||
| YR75-4080SC | 4.0 | 80 | 5 | ||
| YR75-5080SC | 5.0 | 80 | 5 | ||
| YR75-6080SC | 6.0 | 80 | 6 |
